Rapid Impact Compactor-RIC Series

Technical Parameters

Introduction
The rapid impact compactor is designed for compacting filler and soft foundation, and can be equipped with excavators and loaders. The impact compactor is a unique rapid tamping equipment with excellent maneuverability, controllability and high efficiency.
Feature
◆Random Monitoring System:
Random monitoring system can make work record, which is convenient to control quality and collect data. The record data include total energy, total penetration degrees, and total settlement.
◆High efficiency:
The advanced technology and economical work method make the rapid impact compactor efficient, and the rapid impact compactor can be widely applied to various soft soil and backfill soil.
◆Security:

That hammer feet touch the ground directly all the time avoids the danger which happens when hammer feet fall and that fragments splash.
◆Multifunction
Rapid impact compactors can be equipped with excavators and loaders. Rapid impact compactors move and transfer quickly and can work in the narrow and low area, such as storage.

Work Range
◆large oil depot
◆port
◆airport
◆parking lot
◆expressway



Technical Parameters
SPEC   RIC5 RIC7 RIC9
Height of Rig m 7.5 7.5 7.5
Width if Rig m 3.55 3.55 3.55
Ram Weight ton 5 7 9
Max Drop m 1.2 1.2 1.2
Max Energy tm 6 8.4 10.8
Blows per min times 40-60 40 60
Foot dia m 1.5 1.5 1.5
