Submarine Pump DOP-Submarine Pump

Submarine PumpDOP Submarine Pump



Damen Dredging

With our roots in the Netherlands, Damen has a natural insight into water management. With our considerable knowledge and experience Damen designs and builds robust and powerful Dredgers and components.
Standardisation


Damen’s standard designs offer numerous advantages:
•    - Fast delivery
•    - Competitive pricing
•    - Tried & tested technology
•    - Best price-quality ratio
•    - High resale value

Hulls in stock
To reduce delivery times to a minimum, we build vessels for stock. Customers can fine-tune their vessel with a large range of options to meet their specific requirements.

Research & Development
Utilising the latest CFX flow prediction software and valuable customer feedback, Damen’s R&D teams recently developed a new range of drag heads. The result? Improved dredging production.

Capital Dredging
1.Cutter Suction Dredger
2.DOP Dredger
3.Trailing Suction Hopper Dredger
4.Trailing Pipe System
5.DOP Pump

Maintenance Dredging
1.Cutter Suction Dredger
2.Booster Station
3.Trailing Pipe System


Dredging Services

1.Shoalbuster
2.Multi Cat
3.Multi Purpose Vessel
4.Utility Vesse



Technical Parameters
    DOP150 DOP200 DOP250 DOP350L DOP350 DOP450L
performance Hinge Suction Capacity 600m³/hr 800m³/hr 1250m³/hr 2400m³/hr 2400m³hr 4000m³/hr
  Pump Speed 80kW 120kW 195kW 180kW 360kW 400kw
size Suction diameter 150mm 200mm 250mm 350mm 350mm 450mm
  Sand flushing connection 180mm 200mm 250mm 350mm 350mm 450mm
Driving Force Hydraulic Pressure spherical 77mm 125mm 130mm 180mm 150mm 165mm
  Max Flow 200l/min 300l/min 485l/min 440l/min 900/min 1000l/min
  Pressure(delta p) 250bar 250bar 250bar 250bar 250bar 250bar
Cutting head The most powerful 13kW 17kW 28kW 47kW 47kW 60kW
Basic weight   1100kg 1360kg 2425kg 5250kg 5330kg 9250kg
